China Cast Iron Junction Box Manufacturers, Suppliers, Factory

• Over voltage protecition: 230V-300VAC
• Under voltage protection : 145-210VAC • Over current protection: 1A-63A
• Recovery Delay Time: 3s-300s
• Product description: The automatic recovery over voltage and under voltage protective device complies with modular design standards. the circuit boards of products adopt good quality electronic components with reliable pe

A SPD Surge protector or simply a surge protector is a device used to protect electronic devices from power surges or transient voltage. This device is connected in parallel to the power supply circuit of the loads that it has to protect. It can also be used at all levels of the power supply network.

▪ Frame size (A): 1600, 2000, 3200, 4000
▪ Breaking capacity: N,S,H
▪ Rated operational voltage Ue (VAC): 380/400/415
▪ Number of poles: 3P, 4P
▪ Installation method: draw-out type, fixed type
▪ Wiring type: horizontal rear connection

The primary wiring diagram to see the picture. The control power is derived from normal power，emergency power cand N phases. Ⅰ and Ⅱ line control power AC220V connected with terminal 102~103,104~105respectively,102 and 104 are normal power and emergency power live line respective. Terminal 101,106 are acting as a signal lamp to control the power supply. Note:101 and 106 couldn’t be connected with any other lines. When above(under) input line, under(above)terminal Ⅰ and Ⅱ line A, B, C phases will be connected with copper lines or lines acting as output.

2MEC Series Metal consumer unit is designed for safe, reliable distribution and control of electrical power as service entrance equipment in residential, commercial and light industrial installations. It had reasonable design and economic cost.

Siemens' comprehensive outdoor portfolio of switching devices and vacuum circuit breakers is designed for a wide variety of applications and climatic conditions. Type-tested reliability as well as long electrical life and mechanical robustness help to minimize operation costs while increasing resiliency of medium-voltage smart grids.
