TYPEHWS-T10HWS-T12HWS-T20HWS-T21HWS-T25KWHP(AC1-3Rated powerlAC-3)IEC60947-4220V2.22.73.745.5380V2.747.57.511Rated operotedcurrent(AC-3)GB14048.4220V1113182026380V79182025Conventional thermol current(Al2020203232Rated insulated voltage(V690Auxiliarycontoct[AC-15] Standard1NO1NO+1NC2NO+2NCRotedcurren......
TYPE |
HWS-T10 |
HWS-T12 |
HWS-T20 |
HWS-T21 |
HWS-T25 |
||
KWHP(AC1-3 |
220V |
2.2 |
2.7 |
3.7 |
4 |
5.5 |
|
380V |
2.7 |
4 |
7.5 |
7.5 |
11 |
||
Rated operoted |
220V |
11 |
13 |
18 |
20 |
26 |
|
380V |
7 |
9 |
18 |
20 |
25 |
||
Conventional thermol current(Al |
20 |
20 |
20 |
32 |
32 |
||
Rated insulated voltage(V |
690 |
||||||
Auxiliary |
|
Standard |
1NO |
1NO+1NC |
2NO+2NC |
||
Roted |
120V |
6 |
|||||
220V |
3 |
||||||
Electrical life |
200 |
||||||
Mechanical life |
1000 |
||||||
Overall dimension |
36x75×78 |
43×75×78 |
63x81x81 |
||||
Installaton dimension |
28×60 |
35×60 |
54x60 |
||||
Control coil |
AC24V 24 |
||||||
AC48V 48-50 |
|||||||
AC100V 100~127 |
|||||||
AC200V 200~240 |
|||||||
AC30V 260~300 |
|||||||
AC400V 380-400 |
|||||||
AC500V 460-550 |
